Products
Specifications & Applications
Our State-of-the-Art Factory with high end machinery help us to meet our customer demand and keep us growing vertically to achieve new milestone each passing years.
All compounds are manufactured on the most sophisticated and modern twin screw & two stage kneader compounding line ensuring maximum degree of blending and dispersion to give ultimate performance at customer end.
HDPE Black Sheathing/ Jacketing Compound
Grade-GIHD:9501UV (CACT Approved grade)
Specifications:
- ASTM D 1248 Type-III, Class-C, Category 4 & 5, Grade J4, J5
- BS 6234: Type H03C
- TEC spec no. GR/TX/ORM-001/05 DEC.17, Section- III
Application:
Optical Fibre Cables used for long-distance and high-performance data networking, telecommunication services, such as Internet, Cable Television and Telephones.
LDPE Black Sheathing/ Jacketing Compound
Grade-GILD:9301 (CACT Approved grade)
Specifications:
- ASTM D 1248 Type I, Class C, Category 5, Grade J3
- BS 6234: Type 03C
- TEC spec no. GR/CUG-01/03 Aug’ 2003
Application:
Jelly filled Telecom Cables (PIJF) Sheathing and Jacketing and Drop wire Cable
HDPE Black Compound
Grade-GIHD:9601 (Power Cable grade)
Specifications:
- IEC 60502, IEC 60708, IEC 60840 Type ST3 & ST7
- BS 6234: Type H03C, ST2
- ASTM D 1248 Type-III, Class-C, Category 4 & 5, Grade J4, J5, E8, E9, W8, W9
Application:
Medium / High Voltage Power & Aerial Bunched Cables Insulation, Sheathing/ Jacketing Application
PE Black Sheathing/Jacketing Compound
Grade: PE-A
Specifications:
- Customized
Application:
CATV Cable Jacketing, OF Cable Sheathing and LT AB Cable Insulation
Halogen Free Flame Retardant (HFFR) Cable Compound
Grade: G-HFFR10
Specifications:
- IEC 332-1 / IEC 332-2
- BS 7655: Section 6.1
- VDE 0207 PART 24 HM2 & HM4
- EN 50363-7:2005
Application:
Insulation and Sheathing for Power cables, Telecommunication cables & Building Wires.
NYLON-6 Compound (Impact Modified)
Grade: G-Lon112
Customized Specification of Cable Insulation and Jacketing.
- Optical Fibre Cable Jacketing
Application:
Protective Jacketing in THHN, THWN Construction in both residential and commercial application & Optical Fibre Cable Jacketing.
Anti-Termite
Anti-Rodent Masterbatch G-Batch: 9102LL
Specifications:
- Customized
Application:
Commonly used in Pipe & Cable Jacketing to protect from Termite and Rodent
Desiccant Masterbatch
G-Batch: D110
Specifications:
- Customized
Application:
Used as drying agent to remove moistures during processing of Cable jacketing/ blown film/moulding/raffia and lamination.
